Limestone Crushing Cone Crusher Less Than 30 Mm Discharge Size Low Speed Operation
Product Description
This mechanical Cone Crusher is a new type of stone making equipment that improves the technology of the original low-speed vertical shaft cement clinker crusher, and meets the user's requirements for various aspects of equipment operation.
The main components of the mechanical Cone Crusher include the main barrel, main shaft, drum assembly, driving gears, dynamic breaker plate, static breaker plate, reducer, and motor.
Mechanical Cone Crusher is mainly used in cement, chemical industry and aggregate manufacturing industry.
Equipment Advantages
1. The rotating speed of the Cone Crusher is low, and the whole machine runs stably, safely and reliably.
2. The crushed aggregate has less dust and powder, no more than 3-5%.
3. V-shaped spiral crushing mode is adopted for the equipment to reduce the number of aggregate crushing surfaces and repeated crushing.
4. The Cone Crusher has been improved, which is more energy saving and environmental protection.
5. The Cone Crusher covers a small area, reduces the basic investment and reduces the production cost of the enterprise.
Technical Reference Data
| Model | Maximum feed side length (mm) | Average feed size (mm) | Discharge port adjustment range (mm) | Production capacity (t/h) | Power (kw) | Rotating speed (r/min) | Weight (t) |
| Clinker | Limestone | Clinker | Limestone | Clinker | Limestone | Clinker | Limestone |
| XCLA-1200 | ＜100 | ≤50 | ≤40 | ≤5 | ≤30 | 10-15 | 18-30 | 11 | 15-18.5 | 8-25 | 6.5 |
| XCLA-1600 | ＜100 | ≤50 | ≤50 | ≤5 | ≤30 | 15-25 | 35-60 | 15 | 18.5-22 | 8-25 | 9.2 |
| XCLA-1800 | ＜110 | ≤50 | ≤60 | ≤5 | ≤30 | 25-35 | 65-100 | 18.5 | 22-30 | 8-25 | 12.6 |
| XCLA-2400 | ＜125 | ≤50 | ≤70 | ≤5-8 | ≤30 | 40-50 | 120-175 | 30-37 | 37-45 | 4-18 | 19.8 |
| XCLA-3200 | ＜150 | ≤50 | ≤80 | ≤5-10 | ≤30 | 58-90 | 150-200 | 45-55 | 55-75 | 3-18 | 26.5 |
